The Juniper Networks® EX3400 Ethernet Switch with Juniper Networks Junos® Fusion Enterprise and Virtual Chassis technology provides enterprises with the flexibility and ease of management that previously was only available with higherend access switches.

Hardware Specifications

- Switching Engine Model: Store and forward

- DRAM: 2 GB with ECC

- Flash: 2 GB

- CPU: Dual Core 1 GHz

- GbE port density per system: 30 (24 host ports + four 1/10 GbE and two 40GbE uplink ports)

- Physical Layer

• Cable diagnostics for detecting cable breaks and shorts

• Auto medium-dependent interface/medium-dependent interface crossover (MDI/MDIX) support

• Port speed downshift/setting maximum advertised speed on 10/100/1000BASE-T ports

• Digital optical monitoring for optical ports

- Packet-Switching Capacities (Maximum with 64-Byte Packets): 288 Gbps

Software Specifications

- Layer 2/Layer 3 Throughput (Mpps) (Maximum with 64 Byte Packets): 214 Mpps

- Layer 2 Features:

• Maximum MAC addresses per system: 32,000

• Jumbo frames: 9216 bytes

• Number of VLANs supported: 4,096

• Range of possible VLAN IDs: 1-4094

• Port-based VLAN

• MAC-based VLAN

• Voice VLAN

• Layer 2 Tunneling Protocol (L2TP)

• Compatible with Per-VLAN Spanning Tree Plus (PVST+)

• RVI (routed VLAN interface)

• Persistent MAC (sticky MAC)

• RSTP and VSTP running concurrently

• IEEE 802.1AB: Link Layer Discovery Protocol (LLDP)

• LLDP-MED with VoIP integration

• IEEE 802.1ae Media Access Control Security (MACsec)

• IEEE 802.1ak Multiple VLAN Registration Protocol (MVRP)

- Backplane: 160 Gbps (with QSFP+ ports) or 80 Gbps (with SFP+ ports) Virtual Chassis interconnect to link up to 10 switches as a single logical device

- Uplink: Fixed 4-port uplinks can be individually configured as GbE (SFP) or 10GbE (SFP+) ports; 2 x 40G QSFP+ ports.

For more detail, visit EX3400 ETHERNET SWITCH DATASHEET
